CR 1018 Diesel Common Rail Fuel Injectors And High Pressure Fuel CR Pump Test Bench

CR 1018 Diesel Common Rail Fuel Injectors And High Pressure Fuel CR Pump Test Bench

1. Fully automatic testing of the sealing performance of electronic fuel injectors from Bosch, Denso, Delphi, Siemens, Caterpillar, Cummins, etc.; various performance curves including full-load flow, return flow, idle flow, and pre-injection flow. It also features built-in piezoelectricity, eliminating the need for an additional computer board.

2. Test BOSCH CP1/CP3/CP4/CP5, DENSO HP0/HP3/HP4/HP5/HP6,CAT 320D, CUMMINS,DELPHI, SIEMENS high pressure CR pump.

3. Uses original imported flow sensors for accurate testing. Test data is rigorously tested and compiled by professional technicians, closely approximating Bosch's original factory data.

4. Generates Bosch IQA codes, Cummins XPI QR codes, Denso QR codes, Delphi QR codes, and Siemens QR codes.

5. Injector response time testing-BIP

6. Injector armature stroke and lift testing.

7. Solenoid valve resistance testing.

8. Solenoid valve inductance testing.

9. Opening pulse width testing.

10. Opening pressure testing.

11. Server-side real-time updates of system data.

Voltage: 380V ,220V
Power: 11kw
